Overview
Design for precision shooters
Designed and engineered for sub-MOA precision shooting. The ES line shares the same optical system and the machining/assembly tolerance that can provide high resolution at high power, maintaining a generous eye box for shooters while holding up to 6000j post-barrel muzzle velocity.
Stainless steel capped turret
The ES riflescope features a stainless steel capped turret, which produces a distinct and audible clicking sound, providing positive feedback to the shooter. It has a toolless reset-to-zero design, and the cap protects the turret from the elements during outdoor use.
The ES scope is available in MIL/MIL (10 MIL per turn) matching turret/reticle configuration. Additionally, it comes equipped with the latest MHP mil-hash reticle, which has been specifically designed to minimize obstruction of the shooter’s view and provide long-range holdover capabilities.
Springer Rated
ES line has undergone extensive testing by champion shooters for over a year, using a springer rifle. It has proven to be durable and reliable, making it suitable for use with centerfire rifles as well.
What comes in the box:
3” sunshade, Lens covers.
Technical Specification
|
OPTICAL DATA |
|
|
Magnification (High) |
16X |
|
Magnification (Low) |
4X |
|
Objective Diameter (mm) |
44mm |
|
Outer dia. Objective (mm) |
52mm |
|
FOV (min.mag - max.mag) (ft@100yds) |
27.2ft - 6.8ft |
|
FOV (min.mag - max.mag) (m@100m) |
9.06m - 2.26m |
|
FOV (min.mag - max.mag) (degree) |
5.18° - 1.3° |
|
Eye relief (min.mag - max.mag) (in) |
3.8'' - 3.5'' |
|
Eye relief (min.mag - max.mag) (mm) |
96.52mm - 88.9mm |
|
Exit Pupil (min.mag - max.mag) (mm) |
11mm - 2.75mm |
|
Diopter Range (dpt) |
+/- 2.0 dpt |
|
Parallax Adjustment |
10 yds - infinity |
|
Coating |
Fully multi-coated |
|
MECHANICAL DATA |
|
|
Tube Construction |
One-piece tube, aircraft aluminum |
|
Elevation Adjustment (value per click) |
0.1 MRAD |
|
Windage Adjustment (value per click) |
0.1 MRAD |
|
Turret Style (Elevation) |
Low profile, toolless resettable zero |
|
Turret Style (Windage) |
Low profile, toolless resettable zero |
|
Travel Per Rotation |
10 MRAD |
|
Elevation adj. range |
≥ 18 MRAD |
|
Windage adj. range |
≥ 18 MRAD |
|
Eye Piece Diameter (in) |
1.73'' |
|
Eye Piece Diameter (mm) |
44mm |
|
Eye Piece Length (in) |
3.70'' |
|
Eye Piece Length (mm) |
94.0mm |
|
Mounting Length rear (mm) |
57.6mm |
|
Mounting Length front (mm) |
59.6mm |
|
Tube Dia. (mm) |
30mm |
|
Length (in) |
13.94'' |
|
Length (mm) |
352mm |
|
Weight (g) |
702g |
|
Weight (oz) |
24.76oz |
|
Surface Finish |
Matte Black |
|
ENVIRONMENT DATA |
|
|
Functional temperature |
-20 ~ 50 degree celcius |
|
Storage temperature |
-20 ~ 50 degree celcius |
|
Submersion tightness |
IPX7 |
|
RETICLE DATA |
|
|
Reticle |
MRAD-MHP10i |
|
Calibrated Ranging Power |
10X |
|
Focal plane |
Second Focal Plane |
|
Illumination |
6 Steps illumination with off setting in between |
|
DELIVERY INCLUDE |
|
|
Standard Accessories |
3" sunshade, lens covers |
Reticles
 |
|
|
MRAD-MHP10i |
